516 SA/1
Cabinet with 6 drawers
- Fully opening drawers on telescopic ball bearing slides Colore da utilizzare per codici novità
CMYK: 45-0-100-0
- Opportunity to store 3 modules in each drawer
- Drawer handles i high resistant ABS
- Possibility of mounting lateral accessories such as waste holder 519 RA1,
bottle holder 519 RA5, document holder 519 RA2, roll holder 519 RA4
- Oil-proof rubber mats inside
- Centralized locking system
- Supplied with bottle holder system that can be positioned on the right or left
side - spare part SER.SBN1
- Sheet steel casing and drawers with epoxy process, colour black RAL 9004
- Drawers can be equipped with separators 519 SB
- Maximum loading capacity: 1,000 kg
- Possibility to use the raising support 516 SA/11, to increase height up to
1006 mm (including worktop)
- Possibility to use the adjustable feet 516 SA 15 when the floor is not perfectly
level
- Drawer loading capacity: 20 kg for drawers h 60 mm, 25 kg for drawers
h 130 mm and 30 kg for drawer h 200 mm
- Inside dimensions of the drawers:
3 drawers 570x420x60 mm
2 drawers 570x420x130 mm
1 drawer 570x420x200 mm

LxPxH code Q.tà x conf. €
a
Cod.
mm Kg
722x500x812 48 U05160201 1

516 SA/16
START roller cabinet - 6 drawers (empty)
- Ideal to be used in combination with the workshop furniture line 516
Colore da utilizzare per codici novità
CMYK: 45-0-100-0
- Worktop in high resistance ABS
- Double front carrying handle for greater maneuverability
- Fully opening drawers on telescopic ball bearing slides
- Opportunity to store 3 modules in each drawer
- Drawer handles in high resistance ABS
- Oil-proof rubber mats inside
- Centralized locking system
- 4 swivelling oil-proof rubber wheels (Ø 125 mm), two with brakes
- Sheet steel casing and drawers with epoxy process, colour black RAL 9004
- Maximum loading capacity: 800 kg
- Drawer loading capacity: 20 kg for drawers h 60 mm, 25 kg for drawers
h 130 mm and 30 kg for drawer h 200 mm
- Inside dimensions of the drawers:
3 drawers 570x420x60 mm
2 drawers 570x420x130 mm
1 drawer 570x420x200 mm

LxPxH a
Cod.
mm Kg code Q.tà x conf. €
722x550x970 60 U05160216 1
