Page 208 - USAG2021

3 516 SP10V

MODULES START roller cabinet with drawer chest - 10 drawers (empty)
- Work top in high resistant ABS with built-in edges to prevent objects from falling
during transport
- Double transport handle for better manoeuvrability
- Fully opening drawers on telescopic ball bearing slides
- Opportunity to store 3 modules in each drawer
- Drawer handles in high resistant ABS
- Oil-proof rubber mats inside
- Centralized locking system
- Supplied with bottle holder system that can be placed on the side - spare
code SER.SBR2
- Oil-proof rubber wheels (Ø 125 mm): two fixed and two swivelling, one of which
has a brake
- Sheet steel casing and drawers with epoxy process, colour red RAL 3020
- Maximum loading capacity: 800 Kg
- Drawer loading capacity: 20 kg for drawers h 60 mm; 25 Kg for drawers
h 130 mm and Kg 30 for drawer h 200 mm)
- Inside dimensions:
6 drawers 570x420x60 mm
3 drawers 570x420x130 mm
1 drawer 570x420x200 mm

LxPxH code Q.tà x conf. €
Cod.
a
mm Kg
748x515x1440 98 U05160009 1

3 516 SP4V

MODULES START drawer chest - 4 drawers (empty)
- Compatible with Start roller cabinets 516 SP (except 516 SP6SV)
- Work top in high resistant ABS with built-in edges to prevent objects from
falling during transport
- Double transport handle for better manoeuvrability
- Fully opening drawers on telescopic ball bearing slides
- Opportunity to store 3 modules in each drawer
- Drawer handles in high resistant ABS
- Oil-proof rubber mats inside
- Centralized locking system
- Supplied with bottle holder system that can be placed on the side - spare
code SER.SBR2
- Optional wheels and handles: code CHRONO.C4K2
- Sheet steel casing and drawers with epoxy process, colour red RAL 3020
- Maximum loading capacity: 800 Kg
- Drawer loading capacity: 20 kg for drawers h 60 mm and 25 Kg for drawers
h 130 mm)
- Inside dimensions:
3 drawers 570x420x60 mm
1 drawer 570x420x130 mm

LxPxH Cod. Q.tà x conf. €
a
mm Kg code
748x515x470 38 U05160004 1

206
