P. 60

EN 60900 ISO 5748                   EN 60900 ISO 5749
                                            086 VSE                ASME B107.500 087 VSE               ASME B107.500

                                            End cutting nippers - 1000 V        Diagonal cutting nippers - 1000 V
                                            - Burnished finish                  - Burnished finish
                                            - Bimaterial layered insulation with ergonomic grip surface  - Bimaterial layered insulation with ergonomic grip surface
                                            - The insulation is in critical condition when the yellow   - The insulation is in critical condition when the yellow
                                            layer becomes visible.
                                                                                 layer becomes visible.
       085 EX/SE3                           - Each one is tested according to the European standard   - Each one is tested according to the European standard
       Assortment with combination pliers, half-  EN 60900 to ensure safe work   EN 60900 to ensure safe work
       round nose pliers with straight jaws and
       diagonal cutting nippers - 1000 V (3 pcs.)
                                             L      N/mm 2     Cod.  Q.tà x conf.  €  2000 N/mm 2
                                                                    a
                                                                                                        a
                                                                                                   Cod.
                                                              code
       - Half-round extra-long nose pliers with straight jaws    mm  gr                    gr     code  Q.tà x conf.  €
        081 EX 160                           165   1,6    250  U00860104        1  1,4     210   U00870102        1
       - Combination pliers 085 EX 180                                             1,6     270   U00870104        1
       - Diagonal cutting nippers 087 EX 160                                       1,8     370   U00870106        1

                                a
                          Cod.
               gr         code  Q.tà x conf.  €
              600        U00850121  1









                                                                        ISO 5749
                                            087 EX                     EN 60900
                                            Diagonal cutting nippers -
                                            1000 V
                                            - Lengthened and pointed head
                                            - Clean and precise cut even on the extremities of cutting
                                            edges
                                            - Additional induction hardening on cutting edges        EN 60900 ISO 5749
                                            - Ideal to cut soft, semi-hard and hard wire  087 VSE R    ASME B107.500
                                            - Fulcrum closer to the cutting edge to reduce effort during   Diagonal cutting nippers for Copper - 1000 V
                                            cutting operations
                                            - Open hinge with forged joint      - Burnished finish
                                            - Insulated ergonomic bimaterial grip  - Bimaterial layered insulation with ergonomic grip surface
                                            - Hanging holes at the ends for safety lock systems  - The insulation is in critical condition when the yellow
                                            - Protective enamelled finish        layer becomes visible.
                                            - Each one is tested according to the European standard   - Each one is tested according to the European standard
                                            EN 60900 to ensure safe work         EN 60900 to ensure safe work
                                            - IMQ Certification
                                   ISO 5748           2
                                             L
                                                 2200 N/mm
                                                         a
                                                                    a
       086 EX                      EN 60900  mm  ø max mm  mm  Cod.  Q.tà x conf.  €  L    Cu
                                                              code
                                                                                                        a
                                                                                                   Cod.
                                             140   1,4    17  U00870107  1       mm  ø max mm  gr  code  Q.tà x conf.  €
       End cutting nippers - 1000 V          160   1,6    20  U00870108  1       165   3,5  270   U00870110        1
       - Additional induction hardening on cutting edges
       - Ideal to cut soft, semi-hard and hard wire
       - Fulcrum closer to the cutting edge to reduce effort during
        cutting operations
       - Open hinge with forged joint
       - Insulated ergonomic bimaterial grip
       - Hanging holes at the ends for safety lock systems
       - Protective enamelled finish
       - Each one is tested according to the European standard
        EN 60900 to ensure safe work
       - IMQ Certification
                                a
         L    2000 N/mm 2  a  Cod.  Q.tà x conf.  €
        mm   ø max mm  mm  code
         160  2,0    7   U00860103  1
