For wiring work such as cutting, coat peeling, crimp, etc. ELECTRIC PLIER
Also usable with car wiring work.

Dimensions (mm) Qty./Carton Weight
Models
T1 T2 H1 H2 L (Generally) (g)
CMP-200 53 61 17.9 22.5 220 6 193
0QFO CBSSFM
5 5
-

) )
$MPTFE CBSSFM
CMP-200
WARNING
● The handle is not insulated. Do not use on live lines.
● This product is a simplified crimper which does not have ratchet mechanism.
This is not able to be used for the work guaranteeing the reliability.

Closed barrel crimp Open barrel crimp Wire strip and wire cut Insulated terminal crimp (INS)
Transcription Suitable wiring Transcription Suitable wiring Coaxial cable crimp (3C)
Transcription Suitable terminal Transcription Suitable terminal 2 2
mm AWG sq（Squere） mm AWG sq（Squere）
0.5 For 0.5sq 0.3 For 0.3sq 025 type 0.05 30 0.05sq 0.3 22 0.3sq
1.25 For 1.25sq 0.5 For 0.5sq 040 type 0.08 28 0.08sq 0.5 20 0.5sq
2.0 For 2.0sq 1.25 For 1.25sq 090 type 1.12 26 0.12sq 0.85 18 0.75(f)sq, 0.85sq
0.2 24 0.2sq 1.25 16 1.25sq Japanese Automotive Standards Organization

For removing resin clip of automobiles. CLIP PLIERS
Possible to work in deep place since the tip is bent.
Dimensions (mm) Qty./Carton Weight
Models
L (Generally) (Store Center) (g)
CLP-150 159 6 6 136
Example

CLP-150
WARNING
● Plastic handle is not for insulation. Do not use on live lines.

For removing resin clip of automobiles. CLIP PLIERS
Ideal tool for remove resin clip of thin head.
With a stopper to prevent breakage of resin clip.
Dimensions (mm) Qty./Carton Weight
Models
L (Generally) (Store Center) (g)
CLP-150N 154 6 6 110
Example

WARNING
CLP-150N ● Plastic handle is not for insulation. Do not use on live lines.

404
