283

282 UNI 6752 DIN 1810 Double ended offset bihexagonal ring
wrenches
Hook wrenches with square pin - Chrome Vanadium steel
- For ring nuts - Satin Chrome finish
d b L Cod. Q.tà x conf. € W L Cod. Q.tà x conf. €
a
a
code
mm mm mm code mm mm
16-18-20 2 108 U02820102 2 6x7 167 U02831302 1
22-25-28 2,5 135 U02820103 2 8x9 182 U02831303 1 283 SE12
30-32 2,5 135 U02820104 2 8x10 182 U02831304 1
34-36-38 3 170 U02820105 2 10x11 197 U02831305 1 Set of 12 offset bihexagonal ring wrenches
40-42 3 170 U02820106 2 12x13 218 U02831306 1
45-50 3,5 206 U02820107 2 13x17 245 U02831308 1 - 283/6x7-8x9-10x11-12x13-14x15-16x17-18x19-
52-55 3,5 206 U02820108 2 14x15 238 U02831309 1 20x22-21x23-24x26-25x28-30x32 mm
58-62-65 4 241 U02820109 2 16x17 258 U02831311 1
68-70-75 4 241 U02820110 2 17x19 290 U02831312 1
Cod.
a
80-85-90 5 280 U02820111 2 18x19 290 U02831313 1 Kg code Q.tà x conf. €
92-95-100 5 280 U02820112 2 19x22 296 U02831314 1 3,6 U02831403 1
110-115 5 334 U02820113 1 20x22 316 U02831315 1
120-130 5 334 U02820114 1 21x23 316 U02831316 1
135-145 6 385 U02820115 1 22x24 324 U02831317 1
155-165 6 385 U02820116 1 24x26 328 U02831318 1
180-195 6 466 U02820117 1 24x27 328 U02831319 1
25x28 345 U02831320 1
27x29 353 U02831321 1
27x32 353 U02831323 1
30x32 360 U02831324 1
34x36 440 U02831327 1
36x41 440 U02831329 1
46x50 510 U02831334 1
282 SN
Adjustable hook wrenches with square pin
- For working with a single wrench on nuts of different
sizes

d b L code Q.tà x conf. €
a
Cod.
mm mm mm
15÷35 3,5 168 U02820301 1 283 SE13
35÷50 4 202 U02820302 1
50÷80 5 280 U02820303 1 Set of 13 offset bihexagonal ring wrenches
80÷120 5,5 345 U02820304 1
120÷180 9,5 492 U02820305 1 - 283/6x7-8x9-10x11-12x13-14x15-16x17-18x19-
20x22-21x23-24x26-25x28-27x29-30x32 mm
283 SE5 Kg code Q.tà x conf. €

Cod.
a
Set of 5 offset bihexagonal ring wrenches 4,2 U02831404 1
- 283/8x9-10x11-12x13-14x15-16x17
282 TSN gr Cod. Q.tà x conf. €
a
code
700 U02831402 1
Adjustable hook wrenches with round pin
- For working with a single wrench on nuts of different
sizes
d b L Cod. Q.tà x conf. €
a
mm mm mm code
15÷35 3 168 U02820321 1
35÷50 4 202 U02820322 1
50÷80 5 280 U02820323 1
80÷120 6 345 U02820324 1
120÷180 8 492 U02820325 1

282 TSNA 283 B8
Set of 8 offset bihexagonal ring wrenches
Spare pins 283 SE9
- Spare part for wrench 282 TSN - 283/6x7-8x9-10x11-12x13-14x15-16x17-18x19-
20x22 mm
Set of 9 offset bihexagonal ring wrenches
c Cod. Q.tà x conf. € - Chrome Vanadium steel
a
mm code - 283/6x7-8x9-10x11-12x13-14x15-16x17-18x19- - Satin Chrome finish
15÷35 U02820331 1 20x22-21x23 mm - Supplied in plastic pouch
35÷50 U02820332 1
50÷80 U02820333 1
a
a
Cod.
code
80÷120 U02820334 1 Kg Cod. Q.tà x conf. € Kg code Q.tà x conf. €
120÷180 U02820335 1 1,8 U02831405 1 1,4 U02831411 1
123
