Page 380 - 日本前田TONE

Snap Ring Pliers
Different use for different grip's color
For external For internal

Excellent workability and safety
◦ Integral molding makes it strong in damage .
◦ Straight type & Bent type.
◦ The tip is reverse taper, so can hold the snap ring firmly.

For attaching and detaching the snap ring for external application. SNAP RING PLIERS

Range Tip Dimensions (mm) Qty./ Weight
Models diameter Carton
(mm) (g)
(mm) T L (Generally)
SRPS-125F 3～ 10 0.9 9.0 140 6 105
SRPS-125 10 ～ 25 1.3 9.0 140 6 105
SRPS-175 19 ～ 60 1.8 9.0 180 6 163
SRPS-200 40 ～ 100 2.3 9.0 225 6 216

For
external
SRPS-175 Example

-

5

SNAP RING PLIERS

Tip Qty./
Range Dimensions (mm) Weight
Models diameter Carton
(mm) (g)
(mm) T L (Generally)
SRPS-125BF 3～ 10 0.9 9.0 130 6 108
SRPS-125B 10 ～ 25 1.3 9.0 130 6 108
SRPS-175B 19 ～ 60 1.8 9.0 170 6 163
SRPS-200B 40 ～ 100 2.3 9.0 210 6 215

For
external

SRPS-175B
Example
-

5

CAUTION
Product video
● Before use of snap-ring pliers, wipe oil off snap ring hole and pegs of pliers.

WARNING
378 ● Plastic handle is not for insulation. Do not use on live lines.
