Page 333 - 日本前田TONE

RATCHET RING WRENCH, FLEX HEAD SET 2-in-1 wrench with ratchet mechanism on both side, which can
be adjusted with any angle. The tool is suitable fpr working in
tight space.
Models RMFWB400 Comes with hanging hole for fall prevention cable (only
RMFWB-1820 and 2224).
Contents 4 Items
Models RMFWB- 1012 1416 1820 2224 Good Design award winning item
(inch) 5/16×3/8 7/16×1/2 9/16×5/8 11/16×3/4 Double flex head ratchet type inch size
Across Flat
（mm） 7.9×9.5 11.1×12.7 14.2×15.8 17.4×19.0
● Tool bag (BNRM7L)
● Weight : 0.89kg
● Qty./Carton : 1
※ Tool bag(3 spare pockets).
※ A tool bag is available for separate purchase. Please see P115.
※ In case of out-of-stock, non-locking flex head will be automatically changed to locking flex
head (15˚ angle each turn).
Easy to store and carry!!

RMFWB400

RATCHET RING WRENCH, FLEX HEAD Good Design award

Across Flat Dimensions (mm) Qty./Carton Weight
Models (g)
(inch) (mm) D1 D2 T1 T2 L (Generally) (Store Center)
RMFWB-1012 5/16×3/8 7.9×9.5 16.4 20.0 6.5 7.3 151 10 10 64
RMFWB-1416 7/16×1/2 11.1×12.7 21.8 25.2 7.7 8.6 197 10 10 122 RMFWB-1416
RMFWB-1820 9/16×5/8 14.2×15.8 26.8 31.6 9.0 10.3 230 10 10 187
RMFWB-2224 11/16×3/4 17.4×19.0 31.8 33.9 10.3 11.2 267 10 10 269
● With safety rope attaching hole(RMFWB-1820 and 2224)
※ In case of out-of-stock, non-locking flex head will be automatically changed to locking flex
head (15˚ angle each turn).
※ Inch/mm conversion chart is available in P489.
RMFWB-2224

'MFY IFBE
A safe rope installation example .PTU TVJUBCMF GPS UJHIU TQBDF

'MFY IFBE .PTU TVJUBCMF GPS UJHIU TQBDF

CAUTION ● Use wrench suitably fitted with bolt / nut.
● Do not use with extension pipe etc. 331
● Avoid giving shock by hitting with hammer etc.
