9.5 Improved work efficiency by using a socket holder (aluminum DEEP SOCKET SET(6pt.), with SOCKET HOLDER
type) that allows easy removal.
9.5 6 Models HSL306
mm Contents
3/8 6 Items
Descriptions DescriptionsModels/Specifications
SOCKET (6pt.) 3S- 08L, 10L, 12L, 13L, 14L, 17L
● SH1306 with socket holder (6 items type)
HSL306 ● Package size : w216 x d106 x h52mm
● Weight : 0.46kg ● Qty./Carton : 1
Models HSL312

Contents 12 Items

Descriptions Models
3S- 08L, 09L, 10L, 11L, 12L, 13L,
SOCKET (6pt.)
HSL312 14L, 15L, 16L, 17L, 18L, 19L
● SH1312 with socket holder (12 items type)
● Package size : w326 x d96 x h37mm
● Weight : 1.04kg ● Qty./Carton : 1
※ Socket holder is available for separate purchase. Please see P171 for details.
DEEP SOCKET (6pt.)

Across
Flat
Models (mm) Dimensions (mm) Qty./Carton Weight
(g)
S D1 D2 L1 L d (Generally) (Store Center)
3S-5.5L 5.5 8.8 17 5 54 4 10 6 30
3S-06L 6 9.3 17 5 54 4.5 10 6 30
3S-07L 7 10.7 17 6 54 5 10 6 35
3S-08L 8 11.7 17 6 54 7.5 10 6 35
3S-09L 9 12.6 17 8 54 7 10 6 40
3S-10L 10 14.7 17 8 54 8.5 10 6 40
3S-11L 11 16 17 9 54 9.5 10 6 40
3S-12L 12 18 17 9 54 10.5 10 6 50
3S-13L 13 19 17 9 54 10.5 10 6 70
3S-08L 3S-14L 14 20 18 10 54 11.4 10 6 80
3S-15L 15 21 19 10 54 11.4 10 6 95
3S-16L 16 22 20 11 54 14 10 6 110
3S-17L 17 24 20 11 54 14.5 10 6 120
3S-18L 18 25 21 13 54 15 10 6 145
3S-21L 3S-19L 19 26 21 13 54 16.2 10 6 160
3S-21L 21 29 23 15 64 18 10 6 175
3S-22L 22 30 24 15 64 18 10 6 195
3S-23L 23 31 26 15 64 20 10 6 200
3S-24L 24 32 26 17 64 20 10 6 200

CAUTION
150 'PS IBOE UPPM ● Do not use with power tools.
